149
Worldwide Mail Order Service.
Phone +44 (0)20 7636 1045 Fax +44 (0)20 7636 3655
P
rintmaking
Section 7
Specifications
—Overall length 25 cm, width 23.5 cm, height 17 cm.
Width of roller 18 cm. Beds are made from steel with thickness 0.3 cm.
Adjustment
—By screw down handles which allow the top roller to be raised
or lowered.
Mounting
—on any table or work bench of reasonable structure and rigidity.
Maintenance
—Protect bare metal surfaces if press is kept in a damp
environment unused.
Delivery
cost within the UK is £20.00 ex VAT
Specifications
—Overall length 35 cm, width 43 cm, height 35 cm. Width
of roller 31.5 cm. Diameter of wheel 85 cm. Steel bed with thickness 0.3
cm.
Adjustment
—By screw-down handles which allow the top roller to be
raised or lowered. Window frame required for relief printing.
Mounting
—on any table or work bench of reasonable structure and
rigidity.
Delivery
cost within the UK is £30.00 ex VAT
Overall weight
—31 kg
Construction
—All steel welded construction. Direct drive to lower roller
via a five spoke star wheel. Spokes are removable for transport. Heavy-
duty ball bearings are used throughout, requiring less effort for turning.
Rollers are made from heavy steel tube with centre shafting, machined to a
fine tolerance then polished.
Press height
including table stand—90 cm/35.43”
Supplied
with Press Table.
Maintenance
—Protect bare metal surfaces if the press is being kept in a
damp environment.
Supplied with one 100% woven blanket of 4 mm thickness.
Free delivery within the UK
M
iniature
T
able
P
ress
Type of Print: General Intaglio techniques
and Monotype. Plate thickness needs to be
no higher than 1mm.
S
mall
F
ormat
P
ress
Type of Print: General Intaglio techniques and Monotype. Plate thickness
needs to be no higher than 1mm.
C
ornelissen
T4285
Type of Print: All intaglio/etching engraving and woodcuts. All relief,
linocuts and collographs. Made to order.
Code
Bed size and
Weight
Upper
Roller
Diameter
Lower
Roller
Diameter
ex VAT
inc VAT
YTI18
18.6 cm x 32 cm
6 kg
35 mm 35 mm
162.50
195.00
YTI26
26.8 cm x 42 cm
8.5 kg
35 mm 35 mm
179.17
215.00
Code
Bed size and
Weight
Upper
Roller
Diameter
Lower
Roller
Diameter
ex VAT
inc VAT
YTI31
31.8 x 60 cm
Table Stand
60 mm 60 mm
825.00
181.67
990.00
218.00
Code
Bed size and
Weight
Upper
Roller
Diameter
Lower
Roller
Diameter
ex VAT
inc VAT
T4285
42 cm x 85 cm x
67 kg
110 mm 110 mm
1175.00
1410.00
Presses
